AOI UCL-03

Underwater Close-up Lens for Action Camera & Phone

Specifications

Details

MODEL

AOI UCL-03

DESCRIPTION

Underwater Close-up Lens for Action Camera & Phone

LENS CONSTRUCTION

3 Elements in 3 Groups

MATERIAL All Lens Elements in Optical Glass
Lens Barrel in Hard Anodized Aluminum Alloy
Silicone Front Bumper Ring
LENS COATING All Glass Lens Elements with Multi-layers AR Coating
FIELD OF VIEW (UNDERWATER) 90 Degree
FOCUS DISTANT
(UNDERWATER)

40mm (min.) to 78mm (max.)
From the front lens element to the Subject

LENS MOUNT

Using AOI Quick Release System- 02 (QRS-02)
Lens pre-installed with QR2 Mount
(Compatible with the most popular AD Mount)

OPTIONAL LENS MOUNTS AD-M55-UWL-03 Adapter for UCL-03 with M55 Thread Mount
AD-M52-UCL-03 Adapter for UCL-03 with M52 Thread Mount
DEPTH RATING 60 Meters / 200 Ft.
DIMENSIONS Φ81mm(D) x 28.5mm(H)
WEIGHT

ON LAND

181 g

UNDERWATER

175 g
STANDARD ACCESSORIES Neoprene Front Lens Cap, Rear Lens Cap in QR2 Mount,
Lens Pouch (AOI LPC-01), Lens Secure Line (AOI QRL-01)


*Specifications and Appearances are subject to change without prior notice.
