- Specifications
-
Details
MODEL NUMBER AOI UCS-Q1i-WHT AOI UCS-Q1i-BLK DESCRIPTION Ultra Compact Strobe- Q1i MAIN BODY COLOR White Black MAIN BODY MATERIAL Polycarbonate + Glass Fiber DEPTH RATING 60 Meters STROBE Guide Number G.N.= 22 Color Temperature 5,600K (5,000K with Diffusor) Beam Angles With Diffusor Horizontal- 85°, Vertical- 85° Flash Recharge Time 0.85 Second (Full Power) Number of Flashes 1,500 times (Using Flash Only, Full Power and with 3,100mAh Li-Ion Batteries) Flash Sync. By Fiber Optical Cable (Multi-cores Fiber Optical Cable is Recommended) Pre-flashes Sync. Pre-Flash Auto Learning / P re-Flash Cancellation Flash Modes TTL Mode and i-Macro Mode OMDS RC FLASH (Group A, Channel 1) TTL AUTO, MANUAL,FP TTL AUTO, FP MANUAL SONY TTL,HSS TTL Manual Mode 6 Steps Setting: 1/64, 1/32+0.5, 1/8, 1/4, 1/2 & FULL Modelling Flash 2 Seconds Flashing Duration Flash Test Button Yes LED LIGHTS Maximum Output 700 Lumens Power Control 25%, 50%, 100% and OFF Color Temp. 5600K Beam Angles 45° Burn Time 130 Minutes (Using LED Only, Full Power and with 3,100mAh Li-Ion Batteries.) BATTERY REQUIREMENTS 18650 Li-Ion Rechargeable Battery x2pcs (Battery is not included with the product) Output Current Minimum 5A Battery Length Minimum 69mm STROBE MOUNTING 1" Ball Mount Only (Non-replaceable) DIMENSIONS 125mm (L) x 77mm (W) x 131mm (H) WEIGHT On Land Approx. 550g (Batteries included) Underwater Approx. 90g (Batteries included) STANDARD ACCESSORIES Strobe Diffusor for Q1 Series SD-01 Control Knob Extension for Q1 Series CKE-01 Spare O-ring set for Q1 Series SOR-01 O-ring Remover ORR-02 Silicone Grease (1.5g) Battery Storage Case BSC-18650-2 (Rechargeable Battery is not included)
*Specifications and Appearances are subject to change without prior notice.
