AOI UWL-09PRO

Underwater 0.45X Wide Angle Conversion Lens

Specifications

Details

MODEL

AOI UWL-09PRO
DESCRIPTION Underwater 0.45X Wide Angle Conversion Lens
LENS CONSTRUCTION 6 Elements in 6 Groups
LENS COATING All Glass Lens Elements with Multi-layers AR Coating,
Optical Grade Glass Dome Lens with Inner Surface Multi-layers AR Coating
FIELD OF VIEW (DIAGONAL) 130°(with 28mm Lens)
MAGNIFICATION 0.45X
MINIMUM OBJECT DISTANT 0 mm to the Front Dome Lens
MOUNT SYSTEM M67 Thread
DEPTH RATING 100 Meters / 330 Ft.
LENS BARREL / LENS HOOD Aluminum Alloy with Black Hard Anodized
WEIGHT
(ON LAND / UNDERWATER)
1408 g  (on land)
770 g  (underwater)
DIMENSIONS 139mm (D) X99mm (H)
STANDARD ACCESSORIES

Neoprene Dome Front Cover (DNC-04), Rear Lens Cap (LRC-02),
Lens Secure Line (LSL-02), Type B M67 Adapter (UWL-09P-Type B) with Allen Key
and Carry Case (LPC-02)


*Specifications and Appearances are subject to change without prior notice.
